High-Power LED Driver
The HLD2 board is a programmable power supply for driving high power LEDs in the most demanding applications. Designed for maximum efficiency and control, the HLD2 is capable of delivering up to 30A continuous current with minimal EMI emissions in a very small form factor. It provides real-time current, voltage and temperature monitoring for optimum control and safety. Equipped with I2C, USB and UART interfaces, it is easy to integrate into any system and is perfectly suited for advanced high-intensity lighting solutions requiring precision and reliability.
Technical Data
Features
Electrical Characteristic | Dimensions | ||
| LED Current (Max.) | 30 A | L x W x H | 51 x 48 x 21 mm |
| LED Voltage (Max.) | 16 V | Environmental Conditions | |
| Input Voltage | 19 - 24 V | Storage Temperature | -40 - 85°C |
Output Power (Max.) | 160 W | Operating Temperature | 20 - 85°C |
Rise/Fall Time | 25 µm | Humidity | 10 - 90 % |
- Interface: I²C, USB, and UART
- Trigger input
- On-board temperature sensor
- 12V fan connector with PWM control
- Status LEDs
DLP® Technology Optics Accessories - Information for Download
Datasheet of Accessories for DLP® Subsystems
- HLD2 (PDF)
